Anson Mill Chain Sprocket

Standard and adjustable zinc-aluminum alloy [ZA12] sprockets

SPROCKET
NUMBER		 NO. OF
TEETH		 PITCH
DIA.		 HUB
NUMBER		 MIN.
BORE		 MAX.
BORE		 DISTANCE
THRU’ BORE		 APPROX.
WT. LBS.
ZA7812 12 10.08 ZAH141 1 15/16 2 15/16 4 32
ZA7813 13 10.9 ZAH141 1 15/16 2 15/16 4 34
ZA7814 14 11.72 ZAH141 1 15/16 2 15/16 4 36
ZA7815 15 12.55 ZAH151 1 15/16 3 15/16 4 46
